XT30 is the new connector on the block and it is perfect for Mini RC use! Forget about mini JST or Mini T-connectors or even bulky XT60 for smaller applications, we have designed the XT30 to meet the needs of the mini-revolution. From 250 class Quadcopters to foamy flyers this is the new standard for you!
Made from high-temp Nylon and gold plated spring connectors, both are included in the same injection mold at the time when forming the connector. The XT30 ensures a solid high-amp connection, perfect for applications up to and beyond 35A constant.
XT30, Designed by hexTronik to be more reliable and a better quality connection than Mini Deans T-Connectors and Mini JST for the given size and weight.
There is no patent on the XT30 connector, we hope this product is sold everywhere in the world and dominates the market, reducing customer dependency on the over-priced and underperforming alternatives for this amp class.
• Gold plated Connections
• Long connection contact points for better current flow
• Fills a gap for the Mini connectors
• Small and lightweight
Amps: 30A Continuous
Contact current transfer size: 2x6mm
IMPORTANT: "These are not cheap copied XT30 plugs. These original Nylon XT30 plugs, manufactured by AMASS, can handle over 30A current for extended periods without exceeding 80DegC thanks to their better contact surface area. The plug is also less likely to deform or melt in comparison to copied non-Nylon XT30 plugs."
Product Id: 9015000204-0
